| Parameters | Content |
| Operation Environment | Ambient temperature: 10°C~30°C Relative humidity: 30%~85% Atmospheric pressure: 86 kPa~106 kPa |
| Power Supply | AC 100-240V, 50Hz/60Hz; 60VA |
| Test Principle | FIA |
| Throughput | ≥150T/h (with optional incubator) |
| Display | 7-inch touch screen |
| Dimensions | 263*240*122mm |
| Weight | 3.5kg |
| Sample Type | Whole blood, serum, plasma |
| Built-in thermal printer |
| Test Item | Sample Type/Volume | Reaction Time (Incubation Time+ Reading Time) |
Detection Range | Storage (months) |
Qualification |
|---|---|---|---|---|---|
| Inflammation | |||||
| PCT | Serum, plasma, whole blood, 60μL | 8 min+10s | 0.05-150.00ng/mL | 18 | NMPA CE |
| IL-6 | Serum, plasma, whole blood, 60μL | 8 min+10s | 2.50-4000.00pg/mL | 18 | NMPA CE |
| hs-CRP+ conventional CRP | Serum, plasma, whole blood, 5μL | 2 min+10s | 0.50-200.00mg/L | 18 | NMPA CE |
| SAA | Serum, plasma, whole blood, 5μL | 2 min+10s | 5.00-250.00mg/L | 18 | NMPA |
| SAA/CRP Combo Test Kit | Serum, plasma, whole blood, 5μL | 2 min+10s | SAA：5.00mg/L-250.00mg/L CRP：0.50mg/L-200.00mg/L |
18 | NMPA |
| PCT/CRP Combo Test Kit | Serum, plasma, whole blood, 60μL | 8 min+10s | PCT：0.05ng/mL-100.00ng/mL CRP：0.50mg/L-200.00mg/L |
18 | NMPA |
| HBP | Serum, plasma, whole blood, 60μL | 8 min+10s | 6.00-300ng/mL | 18 | NMPA CE |
| Cardiac Marker | |||||
| CK-MB | Serum, plasma, whole blood, 60μL | 8 min+10s | 0.20-300.00ng/mL | 18 | NMPA CE |
| hs-cTnl | Serum, plasma, whole blood, 60μL | 8 min+10s | 0.02-80.00ng/mL | 18 | NMPA CE |
| D-Dimer | Plasma, whole blood, 60μL | 8 min+10s | 0.015-12.000 mg/L | 18 | NMPA CE |
| MYO | Serum, plasma, whole blood, 60μL | 8 min+10s | 7.80-2000.00ng/mL | 18 | NMPA CE |
| BNP | Plasma, whole blood, 60μL | 8 min+10s | 15.00-5000.00pg/mL | 18 | NMPA CE |
| NT-proBNP | Serum, plasma, whole blood, 60μL | 8 min+10s | 30-35000pg/mL | 18 | NMPA CE |
| MPO | Serum, plasma, whole blood, 60μL | 8 min+10s | 10-28000pmol/L | 18 | CE |
| Lp-PLA2 | Serum, plasma, whole blood, 60μL | 8 min+10s | 7.50-1000.00ng/mL | 18 | CE |
| cTnI/ CK-MB/ MYO Combo | Serum, plasma, whole blood, 80μL | 8 min+10s | cTnI：0.02 ng/mL-80.00 ng/mL CK-MB：0.30 ng/mL-300.00 ng/mL MYO：21.00 ng/mL-1000.00 ng/mL |
18 | NMPA |
| ST2 | Serum, plasma, whole blood, 60μL | 8 min+10s | 5.00-200.00ng/mL | 18 | NMPA CE |
| Thyroid | |||||
| T3 | Serum, plasma, whole blood, 80μL | 10 min+10s | 0.40-6.00ng/mL | 24 | CE |
| T4 | Serum, plasma, whole blood, 80μL | 10 min+10s | 1.00-25.00ug/dL | 24 | CE |
| fT3 | Serum, plasma, whole blood, 80μL | 10 min+10s | 0.20-35.00pg/mL | 24 | CE |
| fT4 | Serum, plasma, whole blood, 80μL | 10min+10s | 0.08-8.00ng/dL | 24 | CE |
| TSH | Serum, plasma, whole blood, 80μL | 10 min+10s | 0.10-100.00mlU/L | 24 | CE |
| Hormones | |||||
| AMH | Serum, plasma, whole blood, 60μL | 8 min+10s | 0.1-23ng/mL | 18 | NMPA CE |
| β-HCG | Serum, plasma, whole blood, 60μL | 8 min+10s | 2.0-200000.0mlU/mL | 18 | NMPA |
| COVID-19 | |||||
| SARS-CoV-2 Neutralizing Antibody | Serum, plasma, whole blood, 60μL | 15 min+10s | 20-1500 BAU/mL | 24 | CE |
| Tumor Markers | |||||
| PGⅠ/PGⅡ Combo Test Kit | Plasma, whole blood, 60μL | 8 min+10s | PGⅠ：1.00 ng/mL-200.00 ng/mL PGⅡ：0.50 ng/mL-100.00 ng/mL |
18 | NMPA |
| G17 | Serum, plasma, whole blood, 60μL | 8 min+10s | 0.50 pmol/L-100.00 pmol/L | 18 | NMPA |
| AFP | Serum, plasma, whole blood, 60μL | 8 min+10s | 0.5-350.0ng/mL | 18 | CE |
| CEA | Serum, plasma, whole blood, 60μL | 8 min+10s | 0.5-200.0ng/mL | 18 | CE |
| β2-MG | Serum, plasma, whole blood, 60μL | 8 min+10s | 0.3-20mg/L | 18 | CE |
| Diabetes | |||||
| HbA1c | whole blood, 60μL | 8 min+10s | (NGSP) 4-15% | 18 | CE |
| Cys C | Serum, plasma, 60μL | 8 min+10s | 0.1-7.5mg/L | 18 | CE |
| Others | |||||
| S100-β | Serum, plasma, whole blood, 60μL | 8 min+10s | 0.05-10ng/mL | 18 | NMPA CE |
| Fer | Serum, plasma, whole blood, 60μL | 8 min+10s | 1.5-1,000ng/mL | 18 | NMPA CE |
| Vitamin D | Serum, plasma, 60μL | 8 min+10s | 8-70ng/mL | 18 | CE |
